This Small Smart Space has been designed by a Certified Passive House and Architectural Designer. Designed to have low operating costs and using low embodied carbon materials, this design uses SIPS panel construction, uPVC recessed joinery and Airtightness. This design reduces the operational energy footprint of a typical house. Designed with efficient space and water heating considerations.
This design can be Passive House and Homestar Certified. Designed with Offsite and High-performance materials.Passive House annual power consumption for this design can be no more than 825 kWH/year for heating and cooling and aims to stay at a constant 20 Degrees Celsius year round. Energy Modeling is available as an additional service for this design to access exact specification required for High or Passive House Performance for your specific location.
Design Features include:
•1 Large Bedroom
•Ensuite
•Compact Laundry
•Open Plan living, Kitchen, Dining
Aims to use only 3,000 kWh per year of power for heating, cooling and operation to World Healthy Organisation Standards of interior conditions for health and comfort. . (The average New Zealand Home uses between 8,000 to 9,000 kWh per year with no defined comfort requirements)
This design works really well with renewable energy sources such as PV panels due to the efficiency in the design and specification. Materials with low Carbon embodiment have also been chosen to reduce the Embodied Carbon footprint.
Small Space living needs to be carefully considered to avoid compromising on real life requirements of spaces. Enclosed in a simple form is open plan living with a combined kitchen, dining and living area. Privacy between front door and living spaces has been considered as well as privacy to the bedroom space from the living areas.
Total Floor Area (excluding stair void space) 60m2, 646 FT2 this compact design allows quality living within a small footprint.
Designed by: Smart Living Spaces
The Product
This is an initial set of drawings for planning, getting permits, or getting a local building cost estimate. It acts like a guide to learn more about the design and is not for construction. Dimensions are metric.
Included in this package
•Furniture layout concept plan
•Dimension Floor Plans showing general sizes in both metric and imperial units
•4 x Design Elevations
•Design Sections
•Exterior Door and Window Schedule in both metric and imperial units
•4 x Exterior Perspectives
•4 x Interior Perspectives
•Outline Specification
•3D interactive Virtual Model
Important Information
This Design is for personal use and is not to be used commercially. Should you wish to replicate this design multiple times, please get in contact.
This is a Planning set and is not sufficient information to obtain any building permits or consents. Please check your local Authorities requirements.
The Planning Set does not include a license to build. It is illegal to recreate the plan in part or in full without purchasing the License to Build. Smart Living Spaces makes no warranty of any kind, express or implied, with respect to the content or use of these plans, including without limitation, to any warranty of merchantability or of fitness for a particular purpose. These plans are protected under the terms of international and New Zealand copyright Smart Living Spaces terms and conditions apply to all plans.
Get in touch for:
•Passive House Certification (International)
•Energy Modeling (International)
•Homestar Certified (NZ Only)
•Building Consent (NZ Only)
www.smartlivingspaces.nz/contact
Delivery
Instant Download .Your files will be available to download once payment is confirmed.
All digital documents will be automatically delivered after purchase, through your email address.
Instant download items don’t accept returns, exchanges or cancellations. Please contact the seller about any problems with your order.
ALL digital products provided are property of Smart Living Spaces and are for PERSONAL USE ONLY. You can only build ONE home with this set. If you need to build this home multiple times, please contact us.
Contact
Please contact me if you have any problems with your order.
